UNDERCARRIAGE MLC650 SERVICE/MAINTENANCE MANUAL

8-6

Published 09-09-16, Control # 229-09

Table 8-1. Legend for Figure 8-1 and Figure 8-2

Item Description

1 Pump 3 (left travel / drum 1) (130 cc)

2 Pump 9 (accessory) (45 cc)

3 Pump 3 Pressure Transducer (left track psi)

4 Pump 9 Pressure Transducer (acc systems psi)

5 Left Travel / Drum 1 Diverter Pilot Valve (directional control)

6 Right Travel / Drum 2 Diverter Pilot Valve (directional control)

7 Pump 4 Pressure Transducer (right travel psi)

8 Pump 8 (swing) (100 cc)

9 Pump 4 (right travel / drum 2) (130 cc)

10 Suction Manifold

11 Adapter Frame Valve

12 Travel Brake Release Solenoid Valve

13 Gearbox and Brake Assembly (qty 4)

14 Travel Motor (variable displacement) (160 cc) (qty 4)

15 Swivel

16 Right Travel / Drum 2 Diverter Solenoid Valve

17 Left Travel / Drum 1 Diverter Solenoid Valve

18 Accessory Valve Manifold
