CYLINDER BLOCK/CRANKCASE
Page 4B-16 90-857046R1 NOVEMBER 2001
7. Remove crankshaft from block.
56877
a
b
c
a-Crankshaft
b-Upper Oil Seal
c-Lower Oil Seal
NOTE: Do not interchange main bearings, re-install in their original locations.
8. Remove main bearing halves from crankcase cover and cylinder block.
56878
a
b
a-Main Bearing Halves-Crankcase Cover (4)
b-Main Bearing Halves-Cylinder Block (4)
