BIGFOOT GEAR HOUSING
Page 6B-18 90-857046R1 NOVEMBER 2001
8. If propshaft roller bearing is rusted or does not roll freely, replace bearing. If replacement
is necessary, remove bearing and oil seals using Mandrel* (91-36569) and Driver Rod*
(91-37323). Discard oil seals.
NOTE:
*
From Bearing Removal and Installation Kit (91-31229A7).
a
b
c
91-37323
91-36569
58205
a- Propshaft Roller Bearing
b- Mandrel (91-36569)
c- Driver Rod (91-37323)
9. Remove propeller shaft seals (if not removed with bearing) and bearing carrier O-ring.
51263
a
a- O-ring
