Page #117 background image
6 System Commissioning and Functions NICE3000
new
User Manual
- 116 -
6
â—†
Motor Auto-tuning
1. Parameters related to motor auto-tuning
Function Code Parameter Name Description
F1-25 Motor type
0: Asynchronous motor
1: Synchronous motor
F1-00 Encoder type
0: SIN/COS encoder
1: UVW encoder
2: ABZ incremental encoder
3: ECN413/1313 absolute encoder
F1-12 Encoder pulses per revolution 0–10000
F1-01 to F1-05
Rated motor power
Rated motor voltage
Rated motor current
Rated motor frequency
Rated motor rotational speed
These parameters are model dependent, and
you need to manually input them according to the
nameplate.
F0-01 Command source selection
0: Operation panel control
1: Distance control
F0-01 Command source selection
0: Operation panel control
1: Distance control
F1-11 Auto-tuning mode
0: No operation
1: With-load auto-tuning
2: No-load auto-tuning
3: Shaft auto-tuning
2. Motor auto-tuning owcharts
â–  Synchronous motor auto-tuning
a. Synchronous motor with-load auto-tuning (motor connected with car)
START
Func.
Code
Parameter Name Default Commissioning
Enter inspection state
Turn the Automatic/Inspection switch to the Inspection position.
X9 indicator is OFF, indicating that the elevator enters inspection state.
Select command source F0-01 Command source selection 1 1
0: Operation panel control
1: Distance control
Set motor type
F1-25 Motor type 1 1
0: Asynchronous motor
1: Synchronous motor
