NICE3000
new
User Manual
6 System Commissioning and Functions
- 129 -
6
Table 6-5 Checking light curtain state based on X1 signal indicator
Light Curtain Blocking State State of X1 Signal Indicator
Light curtain signal set to NO
Unblocked Steady OFF
Blocked Steady ON
Light curtain signal set to NC
Unblocked Steady ON
Blocked Steady OFF
If the state of X1 signal indicator keeps unchanged or changes abnormally, it indicates that the light
curtain is abnormal.
Step 3: After light curtain commissioning is completed, check whether the setting of F5-25 Bit0 is
consistent with the actual NO/NC feature of the light curtain.
Table 6-6 Checking consistency between F5-25 and actual light curtain
Signal
Light Curtain State Monitoring
(Segment A of LED1 in F5-35)
Signal State
Judging
Re-set F5-25 Bit0?
Unblocked Blocked
Door 1 light
curtain
signal
A
A
Normal Not required
A
A
Abnormal
Set F5-25 Bit0 to the opposite state:
If the original value is 0, change it to 1.
If the original value is 1, change it to 0.
â–  Door Machine Controller Commissioning
The procedure of door machine controller commissioning is as follows:
Step 1: Check that F7-05 (Door open forbidden) is 0 (No).
Step 2: Check whether the door machine controller wiring is correct and secure and that the power
voltage is proper.
Step 3: Commission the door machine controller, and check whether the input and output of the door
machine controller are normal in terminal control mode.
1) Check that the door open/close output is normal:
Short BM/B1 on the CTB, and door 1 opens; short BM/B2, and door 1 closes. If the door acts
abnormally after you short BM/B1 or BM/B2 on the CTB, check:
a. Whether cable connection between the CTB and the door machine controller is correct
b. Whether the function setting of door open/close input terminals is correct
c. Whether door machine controller commissioning fails. If yes, perform commissioning again.
2) Check whether the door open/close limit signal feedback from the door machine controller is
normal .
Observe the X terminal signal indicators on the CTB and judge whether feedback from the door
