8 Description of Function Codes NICE3000
new
User Manual
- 238 -
8
Figure 8-21 FA-30 Input state 5
RUN
LOCAL/REMOT FED/REV TUNE/TC
0
1
2
4
5
3
6
7
8
9
10
14
11
12
13
15
Present signal No.
State of present
signal
Each segment
indicates a signal
Segment ON: active
Segment OFF: inactive
Display
Meaning
Active
Inactive
...
No.
Signal
No.
Signal
0
1
2
3
4
5
7
Reserved
Reserved
Reserved
Higher-voltage safety circuit signal
Higher-voltage door lock circuit signal
Reserved
Reserved
8
9
10
12
13
14
15
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
11
Reserved
6
Figure 8-22 FA-31 Output state 1
RUN LOCAL/REMOT FED/REV TUNE/TC
0
1
24
5
3
6
7
8
9
10
14
11
12
13
15
Present signal No.
State of present
signal
Each segment
indicates a signal
Segment ON: active
Segment OFF: inactive
Display
Meaning
Active
Inactive
...
No.
Signal
No. Signal
0
1
2
3
4
5
7
RUN contactor control
Brake contactor control
Shorting door lock circuit
contactor control
Fire emergency floor arrival
feedback
Door 1 open
Door 1 close
Door 2 open
8
9
10
12
13
14
15
Door 2 close
Brake and RUN contactors
healthy
Fault state above level 3
Shorting PMSM stator
contactor
Emergency evacuation
automatic switchover
System healthy
Emergency buzzer control
Reserved
11 Running monitor
6
