NICE3000
new
User Manual 12 EMC
- 301 -
12
Controller Model Rated Input Current (A)
AC Reactor Model
(Inovance)
NICE-L-C-4090 180.0 MD-ACL-200-4T-753-2%
NICE-L-C-4110 214.0 MD-ACL-250-4T-114-2%
NICE-L-C-4132 256.0 MD-ACL-330-4T-164-2%
NICE-L-C-4160 307.0 MD-ACL-330-4T-164-2%
Three-phase 220 V, range: 220–240 V
NICE-L-C-2002 11.0 MD-ACL-15-4T-552-2%
NICE-L-C-2003 17.0 MD-ACL-30-4T-113-2%
220-NICE-L-C-4007 20.5 MD-ACL-30-4T-113-2%
220-NICE-L-C-4011 29.0 MD-ACL-30-4T-113-2%
220-NICE-L-C-4015 36.0 MD-ACL-50-4T-153-2%
220-NICE-L-C-4018 41.0 MD-ACL-50-4T-183-2%
220-NICE-L-C-4022 49.0 MD-ACL-50-4T-183-2%
220-NICE-L-C-4030 62.0 MD-ACL-80-4T-303-2%
2. Designation rule
Figure 12-1 Designation rules of AC input reactor
Inovance AC input reactor
Mark
MD-ACL 50
Rated Current
50 A
50
4T 2%
Voltage Drop Percentage
2%
2%
Mark
183
Applicable Power
183
18.5 kW
Mark
4T
380 V
Mark
Rated Voltage
