NICE3000
new
User Manual
3 Mechanical and Electrical Installation
- 49 -
Function Code Parameter Name Setting Range
Default Unit
Property
F5-08 X8 function selection
12/44: Up limit signal NO/NC
13/45: Down limit signal NO/NC
14/46: Overload signal NO/NC
15/47: Full-load signal NO/NC
16/48: Up slow-down 1 signal NO/NC
17/49: Down slow-down 1 signal NO/NC
18/50: Up slow-down 2 signal NO/NC
19/51: Down slow-down 2 signal NO/NC
Others:
00: Invalid
11/43: Fire emergency signal NO/NC
20/52: Up slow-down 3 signal NO/NC
21/53: Down slow-down 3 signal NO/NC
23/55: Fireghter running signal NO/NC
24/56: Door machine 1 light curtain signal
NO/NC
25/57: Door machine 2 light curtain signal
NO/NC
26/58: Brake travel switch 1 NO/NC
27/59: Emergency evacuation signal NO/NC
28/60: Elevator lock signal NO/NC
29/61: Safety circuit 2 feedback NO/NC
30/62: Shorting PMSM stator feedback NO/
NC
31/63: Door lock circuit 2 feedback NO/NC
32/64: Reserved
65/97: Door machine 1 safety edge signal
NO/NC
66/98: Door machine 2 safety edge signal
NO/NC
67/99: Motor overheat signal NO/NC
68/100: Earthquake signal NO/NC
69/101: Back door forbidden signal NO/NC
70/102: Light-load signal NO/NC
71/103: Half-load signal NO/NC
72/104: Fire emergency oor switchover
signal NO/NC
76/108: Door 1 open input NO/NC
77/109: Door 2 open input NO/NC
78/110: Brake travel switch 2 input NO/NC
(End)
22 -
★
F5-09 X9 function selection 40 -
★
F5-10 X10 function selection 09 -
★
F5-11 X11 function selection 10 -
★
F5-12 X12 function selection 44 -
★
F5-13 X13 function selection 45 -
★
F5-14 X14 function selection 48 -
★
F5-15 X15 function selection 49 -
★
F5-16 X16 function selection 50 -
★
F5-17 X17 function selection 51 -
★
F5-18 X18 function selection 00 -
★
F5-19 X19 function selection 00 -
★
F5-20 X20 function selection 00 -
★
F5-21 X21 function selection 00 -
★
F5-22 X22 function selection 00 -
★
F5-23 X23 function selection 00 -
★
F5-24 X24 function selection 00 -
★
