Monarch nice3000 User Manual

NICE3000
new
User Manual Preface
- 5 -
Function Description Remarks
Automatic generation
of optimum curve
The system automatically calculates the optimum speed curve
compliant with the human-machine function principle based on
the distance, without being limited by the number of curves or
short oor.
-
Service suspension
output
When the elevator cannot respond to hall calls, the
corresponding terminal outputs the service suspension signal.
Recorded in F9-05
and F9-06
Running times
recording
In automatic running state, the system automatically records the
running times of the elevator.
Recorded in F9-09
Running time recording
The system automatically records the accumulative power-on
time, working hours, and working days of the elevator.
Fb-09 (Door open/
close protection
times)
Automatic door
open upon door lock
abnormality
If the system detects that the door lock circuit is abnormal during
door open/close, the elevator automatically opens and closes
the door again, and reports a fault after the set door open/close
times is reached.
-
VIP service
The elevator rst directly runs to the VIP oor and provides
services for special persons.
Refer to section 6.1.5
Disability service
When the elevator is waiting at the leveling position, if there is a
call at this oor from the disability operation box, the door open
holding time is prolonged. It is the same for the back door.
Fb-15 (Special door
open holding time)
Full-load direct running
When the car is full-loaded in automatic running state, the
elevator does not respond to hall calls from the passing oors.
These halls calls, however, can still be registered, and will be
executed at next time of running (in the case of single elevator)
or by another elevator (in the case of parallel/group control).
-
Overload protection
When the car load exceeds the rated elevator load, the elevator
alarms and stops running.
Fault data recording
The system automatically records detailed information of faults,
which helps improve the efciency of maintenance and repair.
Group FC
Inspection-related Functions
Simple maintenance
keypad
The 3-button keypad on the MCB provides the functions such as
commissioning the running oors and door open/close.
Refer to section 5.1
Operation box
commissioning
The operation panel can be connected to the system in the car
for elevator commissioning, which improves the commissioning
efciency.
-
Shaft auto-tuning
Shaft auto-tuning is required before rst-time automatic running.
During shaft auto-tuning, the elevator runs from the bottom
oor to the top oor at the inspection speed and automatically
records all position signals in the shaft.
F1-11 (Auto-tuning
mode)
User-dened
parameter display
You can view the parameters that are modied and different
from the default setting.
FP-02
Inspection running
After entering the inspection state, the system cancels automatic
running and related operations. You can press the up or down
call button to make the elevator jog at the inspection speed.
-
Motor auto-tuning
With simple parameter setting, the system can obtain the motor
parameters no matter whether the motor is with-load or without
load.
Refer to section 6.1.3
Floor position
intelligent correction
Every time the elevator runs to the terminal oor, the system
automatically checks and corrects the car position information
based on slow-down switch 1, and eliminates over travel top
terminal or bottom terminal with use of the slow-down switches.
-

Monarch nice3000 Specifications

General

Control Method	Sensorless vector control
Protection Features	Overcurrent, overvoltage, undervoltage, overload, short circuit, overheating
Operating Temperature	-10°C to +40°C
Storage Temperature	-20°C to 60°C
Weight	Varies by model
