SECTION 6
MAINTENANCE
120
5. Wet Printhead Surface. (Ensures that Printhead will prime
correctly.) Moisten Printhead nozzles using distilled water and
a damp, lint-free cloth, wiping end to end. (Gray strip located
below orange strip.) Take care not to damage copper
contacts, metal plate, or gold Printhead surface.
6. Carefully insert Cartridge
into compartment at an angle
[4], with Printhead surface
facing down and Ink Nozzles
facing Ink Hoses. Once
seated, gently tilt Cartridge
back until it snaps into an
upright position [5].
DO NOT FORCE
Printhead Cartridge into
position.
7. Close Printhead Latch [6]. Printer starts up and primes ink into Printhead. (This
may take a few minutes.) Make sure ink is flowing through hoses. If air bubbles
appear, tap lines or click “Circulate Ink” on Touchscreen to clear them.
8. Watch Control Panel
Touchscreen. Check that
Printhead icon [7] in Printer
image is primed (solid color).
9. When ONLINE [8] appears, the
Printer is ready for use. Close
the Top Cover.
NOTE: If the Printhead icon
continues to display an outline or
a question mark (?) try the
following procedures:
[1] Printhead icon shows an outline (Printhead unprimed): Click “Circulate Ink” under
“Maintenance” drop-down in Printer Toolbox. If issue persists, try the “Install Printhead”
procedure again. If this does not clear up the issue, call for technical support.
[2] Printhead icon displays a question mark (Printhead not recognized): Try the “Install
Printhead” procedure again. If the issue continues, call for technical support.
NOTE: Printer may take up to 12 minutes to set itself up during initial startup.
This is normal.
IMPORTANT!
CHECK INK TANKS. PRINTER MAY NOT FULLY REPRIME IF INK TANKS ARE LESS
THAN 1/3 FULL.
