8-7
No. Component Purpose and function
15 Set lower VP limit
increasing SW
SW used to increase set lower VP limit within
acceptable range
16 Set lower VP limit
decreasing SW
SW used to decrease set lower VP limit within
acceptable range
17 DP/AP indicator Indicator used to show DP or AP (option) by bar graph
Upper and lower limits of set DP or AP range are also
shown by different colors.
18 DP indication lamp Lamp used to indicate that DP is shown in DP/AP
indicator
19 AP indicator lamp Lamp used to indicate that AP is shown in DP/AP
indicator
20 Set upper DP/AP limit
increasing SW
SW used to increase set upper DP or AP limit within
acceptable range
21 Set upper DP/AP limit
decreasing SW
SW used to decrease set upper DP or AP limit within
acceptable range
22 Set lower DP/AP limit
increasing SW
SW used to increase set lower DP or AP limit within
acceptable range
23 Set lower DP/AP limit
decreasing SW
SW used to decrease set lower DP or AP limit within
acceptable range
24 Conductivity indicator Indicator used to show conductivity by bar graph
Upper and lower limits of set conductivity range are
also shown by different colors.
25 Total UF volume indicating
LED
LED used to indicate total UF volume at this time
digitally
26 [UF RESET] SW
SW used to reset total UF volume indicating LED
27 Target UF volume
indicating LED
LED used to indicate set target UF volume digitally
28 Set target UF volume
increasing SW
SW used to increase set target UF volume
29 Set target UF volume
decreasing SW
SW used to decrease set target UF volume
30 UFR indicating LED
LED used to indicate set UFR digitally
31 Set UFR increasing SW
SW used to increase set UFR
32 Set UFR decreasing SW
SW used to decrease set UFR
33 Left time indicating LED
LED used to indicate left dialysis time at this time
digitally
