10-5
Alarm
No.
Alarm name
Detection
condition
Detection
process
Audible alarm
Fluid line
function
BP
SP
stop
CLV
close
Alarm
release
Resetting and note
E06 DIALYSATE
TEMPERATURE
MIN ALARM
Dialysate temperature (T3)
of ≦set lower alarm limit
Dialysis
○(3 times)
Auto bypass
― ― ○
Return to normal by pressing [RESET] SW
Auto reset after release from detection
condition for 10 sec
E07 DIALYSATE PRESSURE
MAX LIMIT
Dialysate pressure of
≧+400mmHg
•Rinse wait
•Rinse
•Rinse end
•Air purge
•Dialysis wait
•Preparation
•Preparation end
•Dialysis
•Recovery
•○(7 times)
•Same as above
•Same as above
•Same as above
•○(Continuous)
•Same as above
•Same as above
•Same as above
•Same as above
UF stop
V4,V10 ON for 2
sec
2 sec 2 sec
○
Auto return of BP/SP/CLV to normal
Return of UF stop to normal by pressing
[RESET] SW
E08 DIALYSATE PRESSURE
MIN LIMIT
Dialysate pressure of
≦-400mmHg
•Rinse wait
•Rinse
•Rinse end
•Air purge
•Dialysis wait
•Preparation
•Preparation end
•Dialysis
•Recovery
•○(7 times)
•Same as above
•Same as above
•Same as above
•○(Continuous)
•Same as above
•Same as above
•Same as above
•Same as above
UF stop
V4,V10 ON for 2
sec
2 sec 2 sec
○
Auto return of BP/SP/CLV to normal
Return of UF stop to normal by pressing
[RESET] SW
E09 DIALYSATE PRESSURE
MAX ALARM
Dialysate pressure of ≧
set upper alarm limit
•Dialysis wait
•Preparation
•Preparation end
•Dialysis
•Recovery
○(Continuous)
UF stop
V4,V10 ON for 2
sec
2 sec 2 sec
○
Auto return of BP/SP/CLV to normal
Return of UF stop to normal by pressing
[RESET] SW
Becoming error free of set upper and lower
VP alarm limits by alarm actuation
E10 DIALYSATE PRESSURE
MIN ALARM
Dialysate pressure of ≦
set lower alarm limit
•Dialysis wait
•Preparation
•Preparation end
•Dialysis
•Recovery
○(Continuous)
UF stop
V4,V10 ON for 2
sec
2 sec 2 sec
○
Auto return of BP/SP/CLV to normal
Return of UF stop to normal by pressing
[RESET] SW
Becoming error free of set upper and lower
VP alarm limits by alarm actuation
E11 VENOUS PRESSURE
MAX LIMIT
Venous pressure of
≧+400mmHg
•Rinse wait
•Rinse
•Rinse end
•Air purge
•Dialysis wait
•Preparation
•Preparation end
•Dialysis
•Recovery
•○(7 times)
•Same as above
•Same as above
•Same as above
•○(Continuous)
•Same as above
•Same as above
•Same as above
•Same as above
UF stop
○ ― ○
Return to normal by pressing [RESET] SW
