HOTSPOT GATEWAY
168 System Administration
6. Enter the IP Address of the subscriber.
7. Enter a valid Subnet address for this subscriber.
8. In the Username field, enter a user name for this subscriber. If you entered a
MAC address and you do not want to assign a user name, skip Step 9 (password).
9. If you assigned a user name, you must now assign a Password.
10. In the Expiration Time field, define the duration (in hours and minutes) for the
subscriber’s authorized access time. When the assigned time expires, the
subscriber must “re-subscribe” to the service.
11. Enable or disable the Count-down after Login feature, as required.
12. Enter an amount in the Paid field.
13. The next two fields (User Definable 1 and User Definable 2) are optional. Use
these fields for simple notations about the subscriber.
14. Define the Upstream Bandwidth and Downstream Bandwidth range for this
subscriber (in Kbps).
15. Click on the Add button to add this subscriber to the database, or click on the
Reset button if you want to reset all the values to their previous state.
User names and passwords are case-sensitive. Having a user name and
password is an optional service that subscribers may request (for
example, if they are using more than one machine, or moving between
locations and they want an additional level of security). If they request
this service, they are prompted at the login screen for the user name and
password you assign here. Solution providers can charge a fee for this
service, at their discretion.
