Oki ML1120 Technical Reference Guide

Technical Reference Guide – Operator interface > 57
Top feed
menu
Top feed
wait time
Select the waiting
time between setting
paper on the tray and
feeding it while the
printer is waiting for
paper to be fed in cut-
paper manual feed
mode.
Invalid
500 ms
1 sec
2 sec
Page length
control
Control the page
length of cut paper.
by MENU setting
by Actual page
length
Cut sheet
auto eject
Position
Select a printable
area at the bottom of
cut sheets of paper in
cut-paper mode (the
character centre
position).
6.35 mm (1/4 in)
12.70 mm(6/12 in)
14.82 mm (7/12 in)
TOF
Adjustment
(Cut Sheet)
Select an adjustment
value for the
reference position in
regard to the TOF
position of cut-paper/
passbooks.
The position moves to
the rear of the form
by [+] and to the top
of the form by [-] in
1/144 in increments.
-20 – -1
0
+20 – +1
TOF (cut
sheet top of
form)
Select the reference
position for the TOF
position when feeding
cut-paper in manual
mode. (Up to the
mid-section of
characters in the first
line.)
2.12 mm (1/12 in)
4.23 mm (1/6 in)
6.35 mm (1/4 in)
8.47 mm (1/3 in)
10.58 mm (5/12 in)
12.7 mm (1/2 in)
14.82 mm (7/12 in)
16.93 mm (2/3 in)
19.05 mm (3/4 in)
21.17 mm (5/6 in)
23.28 mm (11/12 in)
25.4 mm (1 in)
27.52 mm
(13/12 in)
Use top of form
Cut sheet LF
adjustment
Adjust a line feed
amount in cut-paper
mode.
-14 – -1
0
+14 – +1
MENU ITEM FUNCTION SETTING

Oki ML1120 Specifications

General

Noise level	49.7 dB
Maximum duty cycle	18000 pages per month
Maximum number of copies	9 copies
Power requirements	120 - 220V
Dimensions (WxDxH)	889 x 587 x 379 mm

Weight and Dimensions

Dimensions (W x D x H) (imperial)	35 x 23.1 x 14.9 \
