APPLIED OPERATIONS/Image Processing
OPERATION INSTRUCTIONS
2-245
Page
4. Click the <Image AND Image> button. A new image window showing [Image AND
Image] in the page tab appears, showing the image obtained by the operation.
Fig. 2-95 [Image AND Image] Panel
2-6-3-7 Image OR Image
Two different images can be ORed.
The operation method is identical to the AND operation between two different images except
for the following point. See section 2-6-3-6, “Image AND Image”.
z Click the <Image OR Image> button. A new image window showing [Image OR Image]
in the page tab appears, showing the image obtained by the operation.
2-6-3-8 Image XOR Image
Two different images can be XORed.
The operation method is identical to the AND operation between two different images except
for the following point. See section 2-6-3-6, “Image AND Image”.
z Click the <Image XOR Image> button. A new image window showing [Image XOR
Image] in the page tab appears, showing the image obtained by the operation.
<Image AND Image>
button
<Image OR Image>
button
<Image XOR Image>
button
