OMICRON 257
Off-service diagnostic methods
Calibration
With Primary Test Manager, you can calibrate analog transducers when using them. To calibrate an
analog transducer:
1. In the Hardware configuration area, select the analog transducer type.
2. In the Settings and conditions area, click Calibrate.
3. In the Transducer Calibration dialog box, enter the maximum stroke of the transducer, and then
click Start.
4. Press the Start/Stop button on the CIBANO 500 front panel.
5. During the calibration time (10 seconds), move the transducer manually from the minimum to
maximum position.
6. After the calibration process has finished, the calculated transducer resolution appears in the
Settings and conditions area.
Measuring pressure signals
With the CB TN3 modules and analog transducers, you can measure and display pressure signals. To
measure pressure signals:
1. Connect at least one CB TN3 module to CIBANO 500.
2. Connect the analog pressure sensors to the analog interface of the CB TN3 module (see
22.2.1 "Designated use" on page 317).
3. In the Hardware configuration area, set the hardware configuration of CIBANO 500 and the
CB TN3 module.
4. Configure the Timing test as described earlier in this section.
Table 17-89: Main contact characteristics
1
1. Only available for O and C sequences
Data Description
Main contact Main contact this measurement row refers to
Travel data CB TN3 channel this measurement row refers to
Contact wipe C sequence: Distance the contact travels between the first contact touch
and the contact steady state
O sequence: Distance the contact travels between the contact steady state
and the final contact separation
Reaction time Time interval after which the contact responds to the open or close signal
(see Begin of contact movement settings in Table 17-16: "Advanced
settings of the Timing test" on page 142)
Bounce time
2
2. Not available for PIR contact system
Duration of the main contact bounce
Bounce count
2
Number of main contact bounces within the bounce time
PIR closing time Closing time for pre-insertion resistors
Assessment Measurement assessment
