Omicron CPC 100 Reference Manual

CPC 100 V1.41
8 - 22
Press the A
DD RAMP button, and repeat steps to to define additional
ramps. Note that the maximum possible number of ramps is 5.
Ramping differentiates two "Overload" trigger conditions:
– the occurrence of an overload (as described above)
– the clearing of an overload condition.
Note: Clearing of an overload condition means: the CB closes
again. For debouncing purposes, at CB closing time
measurements, CPC 100 adds a fixed time of 100ms to the
measured value. In order to determine the true CB closing time
value, these 100ms need to be deducted from the value displayed
in the measurement table (refer to the following example).
– The feature M
ANUAL TRIGGER provides a possibility to manually
initiate a trigger signal (that is, a premature termination) of the
current ramp at any time. This manual trigger has the same
function as an automatic trigger signal.
Trigger threshold.
Only available if a trigger ">" or "<" was selected (refer to ).
9
cont.

10
9
7
10
