CPC 100 V1.41
17 - 18
How to assemble the Odu MINI-SNAP plug
1. Slide cable into backnut, collet and gasket.
2. Strip cable and wire
We recommend tinning the strands with a soldering iron.
3. Solder each wire to its corresponding contact of the insert.
