CPC 100 V1.41
2 - 12
Ext. Booster
Socket to connect an external booster, for example, the CP CB2 current booster
for output currents of up to 2000A.
Enable any external booster in the CPC 100 software on the tab
Options | Device Setup (refer to ”Device Setup” on page 33 of this chapter).
Note: The connector "Ext. Booster" is always galvanically connected to
mains, regardless whether or not an external booster is selected on
the software tab Options | Device Setup, the green warning light (0)
is on, the outputs are turned off or the Emergency Stop button is
pressed.
Handle with extreme caution!
