Omicron CPC 100 Reference Manual

CPC 100 V1.41
2 - 26
Figure 17:
Soft-touch keys to enter
numerical values
Pressing E SC on the soft-touch keyboard while entering a value, discards the
entry and restores the previous value.
When ready, press either the handwheel again or the E
NTER key to confirm
your entry, and move forward to the next UI element of your choice by turning
the handwheel or the U
P /DOWN keys.
Pressing the context-dependent menu key B
ACK TO TOP terminates the data
entry mode, accepts all current values and sets the focus onto the test card tab
designation.
Combo Box
The same principle applies at a combo box, for example, :
– press the handwheel (to "enter" the combo box for selection)
– and either navigate through the list of available parameters by rotating the
handwheel, or by using the U
P /DOWN keys.
Pressing E
SC while scrolling through the list of values closes the combo box
and returns to the previous value.
Check Box
Set the focus onto the check box, for example,
and press
either the E
NTER key or the handwheel to select /clear a check box.
Note: If a number key is pressed with the focus set onto a data entry field,
this number is automatically written to the data entry field, and the field
is enabled for data entry.
Soft-touch keys to
enter numerical
values.
Decimal point
: backspace
Esc: cancels the current
action without saving
— : prefix for negative
values, for example,
angles
: E
NTER
