CHAPTER 6 – Projects OMRON
Page 94 Release 2.0
they are merely not visible. Examples of events are system startup, system shutdown
and user security notices.
The Print button prints the current contents of the error and event log. Ensure that the
printer is correctly set up before printing.
The Display Result Code Converter launches the CX-Server error code converter, and
if a CX-Server error is currently selected, displays further details about possible causes.
The Error Information Dialog button, once pressed, displays a summary of error
information, including a detailed count of errors and PLC communication information.
Click the Close pushbutton to remove this dialog.
Language Settings
The language for user-defined text can be set via the Language Settings dialog. Select Runtime
Settings from the Projects menu, followed by Language Settings to display the Language Settings
dialog.
