CHAPTER 1 – Graphics Editor OMRON
Page 6 Revision 2.0
Before After
Lower Down One
The Lower Down One button allows an object which forms part of an overlapping group of
objects to be moved nearer the bottom of the group, one layer at a time. With an object
selected, clicking the button once moves the object down one layer. This continues until the
object is at the bottom. Clicking the button with the object at the bottom of a group has no
effect.
The following example illustrates the state of a group of two objects before and after clicking the
Lower Down One button with the grey polygon selected:
Before After
Rotate
The Rotate button allows graphical and bitmap objects to be rotated. With an object
selected, clicking the button once opens the Rotate dialog box. Set the desired angle and
click the OK pushbutton to rotate the object.
The following example illustrates the state of an object before and after clicking the Rotate button
and defining a 10° rotation with the object selected:
To Next Page
