OMRON CHAPTER 6 – Projects
Release 2.0 Page 105
Selecting the Pages, Alarms, Recipes, Data Logging or Databases tab displays a list of the associated
components that form part of the project.
The Workspace can be docked to any side of the screen or floated above other windows. To enforce
floating, press <Ctrl> while moving the window.
Project Editor
The Project Editor is activated by clicking the Project Editor button on the toolbar.
When activated, the Project Editor may be displayed minimised at the bottom of the main
CX-Supervisor window. Double click to view the contents of the Project Editor.
About the Project Editor
The Project Editor provides a window into the contents of a project. It lists all the pages currently
comprising a project, and allows for pages to be moved into or out of projects. An example of the
Project Editor dialog is shown as follows:
The Project Editor consists of a control bar and a display area. The control bar includes controls to
filter the pages to be displayed, add and remove pages from a project, and open pages.
Viewing the Contents of a Project
The Project Editor is used to view the pages within a project.
Individual listed pages are sorted, based on the designated page name, page path, project status,
runtime display or load status. By selecting the Page Name field, the pages are sorted
alphanumerically by name. The Page Type, Project Status, Runtime Display and Load Status fields,
once selected, react in the same way. The Project Editor display shows the projects listed in page
name order.
