CHAPTER 10 – Recipes OMRON
Page 170 Release 2.0
Using Recipes in Runtime
Recipes defined using the Recipe Editor in the development environment can be accessed in runtime
using the Recipe Viewer. Recipes may be downloaded using the Recipe Viewer.
Recipe Viewer
The Recipe Viewer can be displayed in one of two ways in the runtime environment. It may be
displayed by any CX-Supervisor script code attached, for example, to a pushbutton. The function
call is simply ‘DisplayRecipes()’.
The Recipe Viewer may also be displayed using the floating menu. The floating menu needs to be
configured to display the Recipes option. This is done in the development environment and
explained in chapter 6, Projects.
The Recipes dialog is displayed as follows:
The Recipe Viewer is similar to the Recipe Editor, however there are some differences in
functionality and appearance:
To remove an existing recipe, highlight the recipe from the recipe list and select the Delete
Recipe button on the toolbar. A confirmation dialog is displayed. Click the Yes pushbutton
to remove the definition, or the No pushbutton to abort the delete operation. Note that
recipes created in the development environment may not be deleted in the runtime
environment. The delete operation only affects recipes copied and saved in the runtime
environment.
To modify an existing recipe, highlight the recipe from the recipe list and select the Modify
Recipe button from the toolbar. The Modify Recipe dialog is displayed as follows:
