OMRON CHAPTER 9 – Animation
Release 2.0 Page 145
Display Page
CX-Supervisor allows the specification of pages within a project for display. This is set up using the
Display Page dialog.
To access the Display Page dialog to add an action, select Display Page from the animation list and
click the Add Action button on the toolbar. To access the Display Page dialog to modify an action,
select Display Page from the animation list and click the Modify Action button on the toolbar. Refer
to chapter 9, Objects, for a list of the objects to which this action is applicable.
On selection of the Display Page action, the Display Page dialog is displayed:
To specify a page for display, select a page from the Available Pages: list and click on the Add
pushbutton. The page entry now appears in the Pages to be Displayed: list. More than one page can
be selected for display. If a selected page is no longer required, select the entry from the Pages to be
Displayed: list, and click on the Remove pushbutton.
Once completed, click the OK pushbutton. To abort the Display Page edit, click the Cancel
pushbutton.
Close Page
CX-Supervisor allows the specification of pages within a project to be removed from the display.
This is set up using the Close Page dialog.
To access the Close Page dialog, select Close Page from the animation list and click the Add Action
button on the toolbar. To access the Close Page dialog to modify an action, select Close Page from
the animation list and click the Modify Action button on the toolbar. Refer to chapter 9, Objects, for
a list of the objects to which this action is applicable.
