Point Attributes
The attributes for a point vary according to the point type.
For a Boolean point, the following attributes are displayed:
The default state of the point is defined by selecting either the State 0: or State 1: setting.
Associative text (such as ‘OFF’ or ‘FALSE’ for state 0) can be applied in the related Default Text:
fields. The default text is associated with Toggle buttons and object animations such as Display
Value and Edit Point Value when they are configured to use the point.
For an Integer point, the following attributes are displayed:
The minimum threshold for the point is inserted into the Minimum Value: field.
The maximum threshold for the point is inserted into the Maximum Value: field.
The default value is inserted in the Default Value: field.
Note: Integer points are limited to -2,147,483,648 to 2147483647
For a Real point, the following attributes are displayed:
The minimum threshold for the point is inserted into the Minimum Value: field. The maximum
threshold for the point is inserted into the Maximum Value: field.
