OMRON CHAPTER 1 – Graphics Editor
Revision 2.0 Page 7
Before Rotated 10°
°°
°
Horizontal Mirror
The Mirror Horizontal button on the Control Bar allows graphical and bitmap objects to be
mirrored in the horizontal plane. With an object selected, clicking the button once “flips” the
object producing a horizontal mirror image.
The following example illustrates the state of an object before and after clicking the Mirror
Horizontal button with the object selected:
Before After
Vertical Mirror
The Mirror Vertical button allows graphical and bitmap objects to be mirrored in the
vertical plane. With an object selected, clicking the button once “flips” the object producing
a vertical mirror image.
The following example illustrates the state of an object before and after clicking the Mirror Vertical
button with the object selected:
Before After
Transparency On/Off
The Transparency button changes an object from solid to outline and from outline to solid.
With an object selected, click the button and the object toggles from solid to outline (or
vice-versa).
