CHAPTER 10 – Recipes OMRON
Page 168 Release 2.0
Copying an Existing Recipe Definition
Open the Recipe Editor dialog, as described in chapter 10, Viewing Recipes in the Recipe Editor.
To copy an existing recipe, highlight the recipe from the recipe list and then type <Ctrl>+C. This
creates a copy of the recipe definition on the clipboard. To paste the recipe definition back in to the
current project, type <Ctrl>+V. The cut, copy and paste operations in the Edit menu may also be
used. The Recipe Editor ensures the name of the recipe is unique by appending a number to the
name. For example, if the original recipe name was “Recipe”, the name of the pasted recipe is
“Recipe1”. All other properties of the pasted recipe remain the same as the original recipe definition.
It is possible to copy many recipes at once by highlighting all the desired recipes in the recipe list.
Press and hold the <Ctrl> key and use the mouse to select recipe definitions one by one, or press and
hold the <Shift> key and use the mouse to select blocks of recipe definitions. Once the desired
recipes have been highlighted, the recipe definitions may be copied and pasted in the usual way.
Deleting an Existing Recipe
Open the Recipe Editor dialog, as described in chapter 10, Viewing Recipes in the Recipe Editor.
To remove an existing recipe, highlight the recipe from the recipe list and select the Delete
Recipe button from the toolbar.
A confirmation dialog is displayed. Click the Yes pushbutton to remove the definition, or the No
pushbutton to abort the delete operation.
Recipe Security Levels
A recipe may be assigned a security level governing which level of users are allowed to download the
recipe in runtime. The available security levels are shown below in descending order:
♦ Designer;
♦ Manager;
♦ Supervisor;
♦ Operator;
