OMRON CHAPTER 4 – Objects
Release 2.0 Page 63
Web Browser Object
The Web Browser object allows web files, like HTML JPG or AVI files to be added to a
CX-Supervisor page. These files may be stored locally, on a File Server or be distributed
from any Web Server. The Web Browser object includes a Java Virtual Machine (JVM) allowing
execution of Java Script and Java Applets. Double click the object to show the property page, and
enter the file to be displayed either as a filename, or a fully qualified URL, for example with http:
prefix.
Manipulating Objects
Once inserted, objects can be manipulated to give the required results. An object must be selected
before it can be manipulated.
Select
To select an object, either click on it with the left mouse button or select it from the object
identification control, (for further details on this control refer to chapter 1, Graphics Editor). Eight
“grab handles” are displayed around the object.
To select several objects within a rectangular area, use a rubber band by clicking the left mouse
button and dragging over an area, as illustrated below:
It is also possible to select all the objects a rubber band intersects by holding down the <Ctrl> key
whilst rubber banding a selection, as illustrated below:
