CHAPTER 4 – Objects OMRON
Page 64 Release 2.0
Multiple objects can be selected by holding the <Shift> key down and clicking on each object in turn.
Objects can also be de-selected in similar fashion. Grab handles are displayed for each selected
object.
The most recent object to be selected from the group is denoted by its green grab handles, all other
grab handles are cyan. The co-ordinates of the most recent selection are displayed in the status bar.
All objects can be selected by clicking Select All from the Edit menu.
Move
To move an object or a number of objects, select them and click and hold the left mouse button
within the selection, the object(s) can now be ‘dragged’ to their new location.
Cut
Where objects are to be moved between pages, it is often useful to cut them without having to insert a
new object. CX-Supervisor has the ability to cut and paste objects. Objects which are cut and pasted
retain the properties assigned to them, for example animation or alarms.
To cut an object from the current page, select it and click the Cut button on the toolbar.
The object is removed from the page and is held on the “clipboard” until a new object is cut or
copied.
Copy
An object which is to appear on a number of pages can be copied from an original. To copy
an object, select it then click the Copy button on the toolbar.
A copy of the object is held on the clipboard, overwriting the previously copied or cut object.
Paste
To paste an object which has been cut or copied to the clipboard, click the Paste button on
the toolbar.
The object currently on the clipboard is pasted, either over the original if the object is to remain on
the same page, or positioned in a new page. Objects can then be re-positioned by selecting and
dragging using the mouse.
Delete
To delete an object or objects, select them and press the <Delete> key on the keyboard.
