CHAPTER 7 – Graphics Library OMRON
Page 110 Release 2.0
Enter the name of the new Library file and click the OK pushbutton, or cancel the addition of the
Library by clicking on the Cancel pushbutton.
If an object is dragged into the Library without a Library file open, then the Add New Library dialog
is displayed. Refer to chapter 7, Manipulating Objects, for details on dragging objects into the
Library.
Opening a Library
The Graphics Library Editor consists of a number of Libraries which are selected from the drop down
list box in the toolbar of the dialog.
Click on the Library name to display its contents in the dialog. The dialog shows the objects in the
selected Library. The content of each library is provided for reference in chapter 7, Manipulating
Objects.
Modify Library
The only element of the Library definition which is editable is the Library name. To change
the name of a Library, open the desired Library file and click on the Modify Library button
on the toolbar. The Modify Library dialog is displayed, an example of which is illustrated as
follows:
Type over the current field entry with a new name and click the OK pushbutton, or cancel the
operation by clicking the Cancel pushbutton.
Delete Library
A Library may be deleted by selecting it from the drop down list, to open it, and clicking the
Delete Library button on the Graphics Library Editor toolbar. CX-Supervisor displays a
message box to confirm the deletion of the Library.
Click the Yes pushbutton to remove the Library or the No pushbutton to cancel the operation and
return to the Graphics Library. After clicking the Yes pushbutton, a second message box is displayed
to confirm deletion of the library.
Click the OK pushbutton to delete the Library, or the Cancel pushbutton to the leave the Library
unchanged.
