2 TECHNICAL DATA
Technical Data REVO nx 130 / REVO nx
OCT Image
Signal source Super Luminescent Diode (SLED)
Wavelength 830 nm
Scanning speed
REVO nx 130 130 000 measurements per second
REVO nx 110 000 measurements per second
Optical power 1575 µW ± -4,5%
Signal analysis Spectral domain Optical Coherence Tomography
Scanning programs 3D, B-scan, Radial HD, Raster, Cross, Angio
1
, Axial length
2
,
Topography
2
Axial resolution 5 µm (in tissue)
Transversal resolution ideal 12 µm
typical 18 µm
Retina scan width 5 – 12 mm
Anterior scan width 3 – 16 mm
Scan depth 2.4 mm / 4.8 mm in Full Range mode
Working distance Posterior segment 23 mm
Anterior segment 52 mm
Anterior segment with adapter 27 mm
Power supply 100 – 240 V, 50 / 60 Hz
Power consumption 115 – 140 VA
Fuse ratings 2 x F 3,15 A L 250 V
Multiple socket-outlet max. load 500 VA
Dimensions 556 mm L × 382 mm W × 469 mm H
Weight 23 kg
1
- OCT Angiography is an optional software module available for the SOCT device. If you do not have this
feature and want to purchase it, contact Optopol’s local distributor.
2
- Biometry and Topography are optional software modules. If you do not have this feature and want to
purchase it, contact Optopol’s local distributor.
