SOCT User Manual Version 10.0 rev. A
Technical Data REVO FC
Fundus Camera REVO FC
Type Type: Non-mydriatic fundus camera
Photography type Photography type Color
Signal source Camera Built-in 12,3-megapixel CCD camera
Angle of view 45 × (1 ± 5 %) °
Light source White LED
Min. pupil size for fundus 3.6 mm
OCT image
Signal source Super Luminescent Diode (SLED)
Wavelength 830 nm
Scanning speed 80 000 measurements per second
Optical power 1150-1250 µW
Signal analysis Spectral domain Optical Coherence Tomography
Scanning programs 3D, B-scan, Radial, Raster, Cross, Angio
5
, Axial length
6
,
Topography
6
Axial resolution 5 µm (in tissue)
Transversal resolution ideal 12 µm, typical 18 µm
Retina scan width 5 – 15 mm
Anterior scan width 3 – 16 mm
Scan depth 2.4 mm / 5 mm in Full Range mode
Min. pupil size for OCT 2.4 mm
Working distance Posterior segment 37 mm, Anterior segment 52 mm
Power supply 100 – 240 V, 50 / 60 Hz
Power consumption 90-110 VA
Fuse ratings 2 x F 4 A H 250 V
Multiple socket-outlet max. load 500 VA
Dimensions 479 mm L × 367 mm W × 493 mm H
Weight 30 kg
5
- OCT Angiography is an optional software module available in REVO FC. If you do not have this feature and
want to purchase it, contact Optopol’s local distributor.
6
- Biometry and Topography are optional software modules. If you do not have this feature and want to
purchase it, contact Optopol’s local distributor.
