SOCT User Manual Version 10.0 rev. A
• REVO FC
Figure 6. The chassis (front and side), applied parts and external fixation of the REVO FC
• REVO
Figure 7. The chassis (front and side), applied parts and external fixation of the REVO
Applied part:
forehead support
Applied part:
chinrest support
External fixation
External fixation
Applied part:
forehead support
Applied part:
chinrest support
External fixation
External fixation
