FP2/FP2SHInstallation and Wiring
4 − 28
4.4 Wiring the Connector Type I/O Units
Correspondence table of 32-point type input unit
When a 32-point type input unit is next to the standard type CPU on the right side.
Terminal
number
Input
number
Terminal
number
Input
number
A1 X0 B1 X8
A2 X1 B2 X9
A3 X2 B3 XA
A4 X3 B4 XB
A5 X4 B5 XC
A6 X5 B6 XD
A7 X6 B7 XE
A8 X7 B8 XF
A9 COM B9 COM
A10 NC B10 NC
A11 X10 B11 X18
A12 X11 B12 X19
A13 X12 B13 X1A
A14 X13 B14 X1B
A15 X14 B15 X1C
A16 X15 B16 X1D
A17 X16 B17 X1E
A18 X17 B18 X1F
A19 COM B19 COM
A20 NC B20 NC
Correspondence table of 64-point type input unit
When a 64-point type input unit is next to the standard type CPU on the right side.
Examples for the CN1 group Examples for the CN2 group
Terminal
number
Input
number
Terminal
number
Input
number
Terminal
number
Input
number
Terminal
number
Input
number
A1 X0 B1 X8 A1 X20 B1 X28
A2 X1 B2 X9 A2 X21 B2 X29
A3 X2 B3 XA A3 X22 B3 X2A
A4 X3 B4 XB A4 X23 B4 X2B
A5 X4 B5 XC A5 X24 B5 X2C
A6 X5 B6 XD A6 X25 B6 X2D
A7 X6 B7 XE A7 X26 B7 X2E
A8 X7 B8 XF A8 X27 B8 X2F
A9 COM B9 COM A9 COM B9 COM
A10 NC B10 NC A10 NC B10 NC
A11 X10 B11 X18 A11 X30 B11 X38
A12 X11 B12 X19 A12 X31 B12 X39
A13 X12 B13 X1A A13 X32 B13 X3A
A14 X13 B14 X1B A14 X33 B14 X3B
A15 X14 B15 X1C A15 X34 B15 X3C
A16 X15 B16 X1D A16 X35 B16 X3D
A17 X16 B17 X1E A17 X33 B17 X3E
A18 X17 B18 X1F A18 X37 B18 X3F
A19 COM B19 COM A19 COM B19 COM
A20 NC B20 NC A20 NC B20 NC
