Panasonic fp2/fp2sh User Manual

Installation and WiringFP2/FP2SH
4 − 29
4.4 Wiring the Connector Type I/O Units
Correspondence table of 32-point type output unit
When a 32-point type output unit is next to the standard type CPU on the right side.
Terminal
number
Output
number
Terminal
number
Output
number
A1 Y0 B1 Y8
A2 Y1 B2 Y9
A3 Y2 B3 YA
A4 Y3 B4 YB
A5 Y4 B5 YC
A6 Y5 B6 YD
A7 Y6 B7 YE
A8 Y7 B8 YF
A9 − B9 −
A10 + B10 +
A11 Y10 B11 Y18
A12 Y11 B12 Y19
A13 Y12 B13 Y1A
A14 Y13 B14 Y1B
A15 Y14 B15 Y1C
A16 Y15 B16 Y1D
A17 Y16 B17 Y1E
A18 Y17 B18 Y1F
A19 − B19 −
A20 + B20 +
Correspondence table of 64-point type output unit
When a 64-point type output unit is next to the standard type CPU on the right side.
Examples for the CN1 group Examples for the CN2 group
Terminal
number
Output
number
Terminal
number
Output
number
Terminal
number
Output
number
Terminal
number
Output
number
A1 Y0 B1 Y8 A1 Y20 B1 Y28
A2 Y1 B2 Y9 A2 Y21 B2 Y29
A3 Y2 B3 YA A3 Y22 B3 Y2A
A4 Y3 B4 YB A4 Y23 B4 Y2B
A5 Y4 B5 YC A5 Y24 B5 Y2C
A6 Y5 B6 YD A6 Y25 B6 Y2D
A7 Y6 B7 YE A7 Y26 B7 Y2E
A8 Y7 B8 YF A8 Y27 B8 Y2F
A9 − B9 − A9 − B9 −
A10 + B10 + A10 + B10 +
A11 Y10 B11 Y18 A11 Y30 B11 Y38
A12 Y11 B12 Y19 A12 Y31 B12 Y39
A13 Y12 B13 Y1A A13 Y32 B13 Y3A
A14 Y13 B14 Y1B A14 Y33 B14 Y3B
A15 Y14 B15 Y1C A15 Y34 B15 Y3C
A16 Y15 B16 Y1D A16 Y35 B16 Y3D
A17 Y16 B17 Y1E A17 Y36 B17 Y3E
A18 Y17 B18 Y1F A18 Y37 B18 Y3F
A19 − B19 − A19 − B19 −
A20 + B20 + A20 + B20 +
