FP2/FP2SHInstallation and Wiring
4 − 30
4.4 Wiring the Connector Type I/O Units
Correspondence table of 32-point input/32-point output type I/O mixed unit
When the I/O mixed unit is next to the standard type CPU on the right side.
Examples for the CN1 group Examples for the CN2 group
Terminal
number
Input
number
Terminal
number
Input
number
Terminal
number
Output
number
Terminal
number
Output
number
A1 X0 B1 X8 A1 Y20 B1 Y28
A2 X1 B2 X9 A2 Y21 B2 Y29
A3 X2 B3 XA A3 Y22 B3 Y2A
A4 X3 B4 XB A4 Y23 B4 Y2B
A5 X4 B5 XC A5 Y24 B5 Y2C
A6 X5 B6 XD A6 Y25 B6 Y2D
A7 X6 B7 XE A7 Y26 B7 Y2E
A8 X7 B8 XF A8 Y27 B8 Y2F
A9 COM B9 COM A9 − B9 −
A10 NC B10 NC A10 + B10 +
A11 X10 B11 X18 A11 Y30 B11 Y38
A12 X11 B12 X19 A12 Y31 B12 Y39
A13 X12 B13 X1A A13 Y32 B13 Y3A
A14 X13 B14 X1B A14 Y33 B14 Y3B
A15 X14 B15 X1C A15 Y34 B15 Y3C
A16 X15 B16 X1D A16 Y35 B16 Y3D
A17 X16 B17 X1E A17 Y36 B17 Y3E
A18 X17 B18 X1F A18 Y37 B18 Y3F
A19 COM B19 COM A19 − B19 −
A20 NC B20 NC A20 + B20 +
To Next Page
