FP2/FP2SH
IC
Memory
Card
7
−
10
7.2
Formatting
and
Erasing
Formatting
the
SRAM
type
With
this
type
of
card,
the
IC
memory
card
must
be
formatted
before
the
program
is
saved
to
it,
and
a
“program
memory
field”
must
be
assured
to
which
the
program
will
be
saved.
This
section
explains
how
this
is
done
using
the
FPWIN
GR.
Procedure:
1.
Booting
the
“F
ormat
IC
Card...”
function.
On
the
“T
ool”
menu,
select
“I
C
Card
Service”
and
then
“F
ormat
IC
Card...”.
The
“Format
IC
Card”
window
opens.
next
page
219
221
