11-21
FP2/FP2SH/FP10SH
Address
Name
Description
R9030
F145 (SEND)/P145
(PSEND) and F146
(RECV)/P146 (PRECV)
instruction executing
flag
Monitors if CPU is in the F145 (SEND)/P145 (PSEND) and
F146 (RECV)/P146 (PRECV) instructions executable
condition as follows:
- off: None of the above mentioned instructions can be
executed.
- on: One of the above mentioned instructions can be
executed.
R9031
F145 (SEND)/P145
(PSEND) and F146
(RECV)/P146 (PRECV)
instruction end flag
Monitors if an abnormality has been detected during the
execution of the F145 (SEND)/P145 (PSEND) and F146
(RECV)/P146 (PRECV) instructions as follows:
- off: No abnormality detected.
- on: An abnormality detected. (communication error)
The error code is stored in DT90039.
R9032 COM port mode flag
Monitors the mode of the COM port as:
- on: Serial data communication mode
- off: Computer link mode
R9033
F147 (PR) instruction
flag
Turns on while a F147 (PR) instruction is executed.
Turns off when a F147 (PR) instruction is not executed.
R9034
Editing in RUN mode
flag
Turns on while editing a program in the RUN mode.
R9035
F152 (RMRD)/P152
(PRMRD) and F153
(RMWT)/P153
(PRMWT) instruction
execution flag
Monitors if FP3/FP10SH is in the F152 (RMRD)/P152
(PRMRD) and F153 (RMWT)/P153 (PRMWT) instructions
executable condition as follows:
- off: None of the above mentioned instructions can be
executed.
- on: One of the above mentioned instructions can be
executed.
