Parts and FunctionsFP2/FP2SH
2 − 31
2.8 Input and Output Units
Table of Input Unit Types
Type Number of
points
Connection
method
Description Part number
DC input
t
16 points Terminal block 12 to 24V DC, sink/source input FP2−X16D2
p
type
32 points Connector 24V DC, sink/source input FP2−X32D2
64 points Connector 24V DC, sink/source input FP2−X64D2
Table of Output Unit Types
Type Number of
points
Connection
method
Description Part number
Relay output
t
6 points Terminal block 5A, Without relay sockets FP2−Y6R
y
p
type
16 points Terminal block 2A, Without relay sockets FP2−Y16R
Transistor
(NPN
16 points Terminal block 5 to 24V DC, 0.5A FP2−Y16T
(NPN open
collector)
32 points Connector 5 to 24V DC, 0.1A FP2−Y32T
co
ll
ec
t
or
)
output type
64 points Connector 5 to 24V DC, 0.1A FP2−Y64T
Transistor
(PNP
16 points Terminal block 5 to 24V DC, 0.5A FP2−Y16P
(PNP open
collector)
32 points Connector 5 to 24V DC, 0.1A FP2−Y32P
co
ll
ec
t
or
)
output type
64 points Connector 5 to 24V DC, 0.1A FP2−Y64P
Note
The maximum load current for the transistor output type output
unit will differ depending on the operating voltage.
Refer to the specifications pages for each unit.
