FP2/FP2SHParts and Functions
2 − 32
2.8 Input and Output Units
Table of I/O Mixed Unit Types
Type Number of
points
Connection
method
Description Part number
DC input/transistor (NPN
open collector) output type
32 input
points/
32 output
points
Connector 24V DC, sink/source input,
5 to 24V DC, 0.1A
FP2−XY64D2T
DC input/transistor (PNP
open collector) output type
32 input
points/
32 output
points
Connector 24V DC, sink/source input,
5 to 24V DC, 0.1A
FP2−XY64D2P
DC input with on pulse
catch input function/transis-
tor (NPN open collector)
output type
32 input
points/
32 output
points
Connector 24V DC, sink/source input,
5 to 24V DC, 0.1A
FP2−XY64D7T
DC input with on pulse
catch input function/transis-
tor (PNP open collector)
output type
32 input
points/
32 output
points
Connector 24V DC, sink/source input,
5 to 24V DC, 0.1A
FP2−XY64D7P
Notes
• The maximum load current value will differ depending on the
operating voltage. Refer to the specifications page for each
unit.
• For types with the on pulse catch input, the four points X1C
through X1F of the 32 input points possess the on pulse catch
input function. (
section 2.11.5)
