Panasonic FP7 User Manual

Automatic Operation (Synchronous Control)
8-8
8.3.2 Types and Contents of Setting Parameters
The use of the electronic gear requires the following parameter settings.
Parameter name Outline
Electronic gear operation
settings
Set to use or not to use the electronic gear function.
The gear ratio of the electronic gear will be set to 1:1 if the electronic gear is not
used, and the operation of the master axis will be input as it is into the electronic
clutch.
Gear ratio numerator
Determines the gear ratio of the electronic gear.
Electronic gear ratio is determined by the following formula.
Output speed of electronic gear = Operating speed of master axis x (Gear ratio
numerator/Gear ratio denominator)
Gear ratio denominator
Gear ratio change time
The time required to change the current gear ratio to a new gear ratio if the new
gear ratio is set for the electronic gear in operation.
