Supplementary Functions
13-10
13.6.2 Monitoring Pulse Input Values
The positioning unit can monitor pulse input from programs.
Pulse input monitoring uses the following areas.
Unit
memory no.
(Hex)
Name Description
UM 00436
Pulse input value of 1st axis
Pulse input values are stored according to the pulse input application
(e.g., pulser, feedback pulse, or high-speed counter). (Unit: pulse)
Pulse input values are integrated and stored, and will be cleared if the
pulse input application is changed or when the pulse input values are
cleared.
UM 00437
UM 00476
Pulse input value of 2nd axis
UM 00477
UM 004B6
Pulse input value of 3rd axis
UM 004B7
UM 004F6
Pulse input value of 4th axis
UM 004F7
