Specifications
17-68
17.7 Unit Memory Synchronous Control Setting Area
17.7.1 Synchronous Control Setting Area
This is an area for monitoring the setting status of synchronous control.
Unit memory no. (Hex) Description
UM 16000 - UM1600F
Synchronous setting
area of 1st axis
Synchronous control common setting area
UM 16010 - UM1601F Electronic gear setting area
UM 16020 - UM1604F Clutch setting area
UM 16050 - UM1606F Electronic cam setting area
UM 16070 - UM1607F
Synchronous setting
area of 2nd axis
Synchronous control common setting area
UM 16080 - UM1608F Electronic gear setting area
UM 16090 - UM160BF Clutch setting area
UM 160C0 - UM160DF Electronic cam setting area
UM 160E0 - UM160EF
Synchronous setting
area of 3rd axis
Synchronous control common setting area
UM 160F0 - UM160FF Electronic gear setting area
UM 16100 - UM1612F Clutch setting area
UM 16130 - UM1614F Electronic cam setting area
UM 16150 - UM1615F
Synchronous setting
area of 4th axis
Synchronous control common setting area
UM 16160 - UM1616F Electronic gear setting area
UM 16170 - UM1619F Clutch setting area
UM 161A0 - UM161BF Electronic cam setting area
UM 161C0 - UM163FF (Not used)
