3.9 Wiring Cautions
Connect the transistor output type or line driver output type to the motor driver over twisted-
pair cable within the following wiring distance.
<Signals supported>
• Transistor output
• Line driver output
• Deviation counter clear output
Output type Model no. Wiring distance
Transistor output type
AFP7PP02T
10 m
AFP7PP04T
Line driver output type
AFP7PP02L
AFP7PP04L
