17.5 Details of Each Axis Information Area in Unit Memory
17.5.1 Each Axis Information & Monitor Area
Axis
information
area
Axis information & monitor area
400H-5FFH
Information of axis 1
Information of axis 2
Information of axis 3
Information of axis 4
Unit memory map
Common area
Each axis
information area
Each axis setting
area
UM 00000
UM 003FF
UM 00400
UM 007FF
UM 00800
UM 00400 - UM 0043F
UM 00440 - UM 0047F
UM 00480 - UM 004BF
UM 004C0 - UM 004FF
Information of virtual axis
UM 005F0 - UM 005FF
Check that the positioning ready flag (X0) is turned ON in the case of reading each
axis information area with a program.
