Panasonic FP7

Specifications
17-20
17.4.6 Positioning Control Starting Table Number Setting Area
Set the starting table number of positioning data on each axis at the time of staring positioning
control.
The setting ranges are 1 to 600 for the standard area and 10001 to 10025 for the extended
area.
Unit
memory no.
(Hex)
Name Description Default Setting range
Set
unit
UM 00100
The starting table number
for the positioning control of
1st axis
Stores the positioning control
starting table number of the 1st axis
1
1 to 600
10001 to
10025
−
UM 00101
The starting table number
for the positioning control of
2nd axis
Stores the positioning control
starting table number of the 2nd
axis
1
1 to 600
10001 to
10025
−
UM 00102
The starting table number
for the positioning control of
the 3rd axis
Stores the positioning control
starting table number of the 3rd axis
1
1 to 600
10001 to
10025
−
UM 00103
The starting table number
for the positioning control of
4th axis
Stores the positioning control
starting table number of the 4th axis
1
1 to 600
10001 to
10025
−
UM 00107
The starting table number
for the positioning control of
the virtual axis
Stores the positioning control
starting table number of the virtual
axis
1
1 to 600
10001 to
10025
−
