17.3 Entire Configuration of Memory Unit Area
17-15
17.3 Entire Configuration of Memory Unit Area
The unit memory is in control of parameter and positioning data set values for the positioning
unit.
All set values are set with the programming tool software or a user program.
Area name
Unit memory
address
Name of each individual area
Common
area
UM 00000
to UM 003FF
Setting parameter control area
Operating speed factor area
Axis group setting area
Current value update data area
Positioning table setting area
Positioning control area
Error annunciation & clear area
Warning annunciation & clear area
Pulse count control area
Synchronous control monitor area
System operation setting area
Each axis
information
area
(Note)
UM 00400
to UM 007FF
1st axis Each axis information & monitor area
2nd axis Each axis information & monitor area
3rd axis Each axis information & monitor area
4th axis Each axis information & monitor area
Virtual axis Each axis information & monitor area
Each axis
setting
UM 00800
to UM 02FFF
1st axis
Parameter setting area
Positioning data setting area
(600 standard points and 25 expansion points)
UM 03000
to UM 05FFF
2nd axis
Parameter setting area
Positioning data setting area
(600 standard points and 25 expansion points)
UM 05800
to UM 07FFF
3rd axis
Parameter setting area
Positioning data setting area
(600 standard points and 25 expansion points)
UM 08000
to UM 0AFFF
4th axis
Parameter setting area
Positioning data setting area
(600 standard points and 25 expansion points)
UM 12000
to UM 147FF
Virtual axis
Parameter setting area
Positioning data setting area
(600 standard points and 25 expansion points)
(Note): Check that the positioning done flag (X0) is turned ON in the case of reading each axis information area with a
program.
