Supplementary Functions
13-8
13.5 Coordinate Origin
The positioning unit performs a home return to set the managing coordinate to 0.
The coordinate origin is a function that allows to set the coordinate to a desired value after
home return processing.
Coordinate origin processing procedure
1. Write an coordinate to be the home in the home coordinate area of the target axis for
which the coordinate is to be changed after a home return.
2. Execute the home return process. After the completion of the home return, the coordinate
specified in the above 1 will become the home position.
Unit
memory no.
(Hex)
Name Default Setting range and description
UM 0084A
UM 0084B
Coordinate origin of 1st axis
−
Stores the value of coordinate origin after the home
return.
UM 0304A
UM 0304B
Coordinate origin of 2nd axis
UM 0584A
UM 0584B
Coordinate origin of 3rd axis
UM 0804A
UM 0804B
Coordinate origin of 4th axis
UM 1204A
UM 1204B
Coordinate origin of virtual axis
Set the coordinate origin in the specified unit.
