5.3 Parameter Settings
5-9
Parameter name Description
Startup speed Startup speed (initial speed) of all types of operation.
Home return – Return setting code The pattern of the home return.
Home return – Return direction The operating direction of the home return.
Home return – Return acceleration time
The acceleration time of the home return.
Home return – Return deceleration time
The deceleration time of the home return.
Home return – Return target speed The target speed of the home return.
Home return – Return creep speed The speed to search the home position after the proximity input.
Home return - Home coordinates Present value on completion of the home return
JOG operation -
Acceleration/Deceleration pattern settings
The acceleration/deceleration type of JOG operation.
JOG operation – Jog acceleration time
The acceleration time of JOG operation.
JOG operation – Jog deceleration time
The deceleration time of JOG operation.
JOG operation – Target speed The target rate of JOG operation.
Emergency stop deceleration time
(ms)
The deceleration time when the emergency stop is requested by the
input contact.
Limit stop deceleration time (ms) The deceleration time of deceleration operation when the limit is input.
Error stop deceleration time (ms) The deceleration time of deceleration operation when an error occurs
J point – Operation setting code The acceleration/deceleration pattern of the J point (speed point)
J point – Acceleration time (ms) The acceleration pattern of the J point (speed point)
J point – Deceleration time (ms) The deceleration pattern of the J point (speed point)
J point – Target speed The target speed of the J point (speed point)
Pulser operation setting code The pulser input (1 to 4) in the pulser operation.
Pulse input method Input type of pulse operation
Pulser operation ratio numerator
The number of movement pulses is calculated from the number of input
pulses of the pulser multiplied by the ratio below.
(Numerator of ratio of pulser operation)/(Denominator of ratio of pulser
operation)
Pulser operation ratio denominator
Pulser operation max. speed The maximum speed of pulse operation
